#WSI-1810-SAAH Inductive Sensor (18mm dia./10mm range) ACTIVSTONE SX

Weld Dynamix, Inc.

#WSI-1810-SAAH specifications                                                                      to all sensors

Inductive Proximity Sensor with ACTIVSTONE SX

Designed to operate in close proximity to weld arc, high-burst temperature, and directed weld spatter applications, as found in automotive welding environments.

  • 18mm Diameter
  • 10mm Sensing Range
  • Weld Immune Electronics
  • Multi-metal sensing (Factor 1) full range on Aluminum and Steel
  • PNP/NO, M12,
  • Stainless Steel face & body
  • IP68/IP69 Rating
  • ACTIVSTONE SX Spatter Resistant Coating
