ACTIVSTONE COATINGS

• ACTIVSTONE SX
  • Standard Coating for Sensors & Mounts
• ACTIVSTONE ZG
  • Zirconium Graphite Composite for High Wear & Heat Applications
• ACTIVSTONE B-SERIES
  • Ultra-thin Vapor Deposition (1um - 5um) for Tooling, Pins, Hardware
• ACTIVSTONE+
  • Ultimate Life for MIG / Casting Tooling Applications (High Temperature & Molten Buildup)
• ACTIVGRIP
  • High-grip Ceramic Coating for High Tactile Requirements
• FLEXKOTE
  • Vapor-Ceramic for flexible steels


7-10 Business Day Leadtime     COATING SHIPPING INSTRUCTIONS



• ACTIVSTONE coatings are application specific, and can be applied to a variety of substrates - including various alloys of steels, stainless steel, aluminum, brass and some non-metallic substrates.

WARRANTY : MATERIALS & WORKMANSHIP

• Weld Dynamix provides a 1-year warranty against defects in materials or workmanship - granted for all coatings and products that are not placed into service - and will be repaired (re-coated) at no cost - at the discretion of Weld Dynamix.

• Weld Dynamix does not offer a warranty for any period after placement into service, due to the nature of harsh  environments (extreme temperatures, impact and abrasion).

TESTING & SAMPLES

Weld Dynamix internal testing to ensure successful applications (thermal, adhesion, abrasion, corrosion, weld spatter resistance, conductivity)

SPECIFICATIONS: ACTIVSTONE B-Series

• Type: Advanced thin-film amorphous carbon coating. vacuum-deposited nanocomposite that mimics diamond (hardness) and graphite (lubricity) properties.
• Primary Purpose: Extreme wear resistance, resistant to spatter adhesion.
• Substrates: All metals (steel, stainless steel, aluminum), complex geometries (details, pins & hardware), and applications requiring ultra thin coating.
• Color: Dark gray to near-black
• Durability & Resistance:
  • Hardness range: Typically 1700–4500 HV (Vickers), 2000–3800 HV range (10x+ harder than uncoated steel
  • Wear/abrasion/scratch resistance: Reduces wear by 5–10x compared to uncoated or standard finishes; excellent against galling and fretting.
  • Thermal: 300°C (570°F) max working temp
  • Very low coefficient of friction
  • High corrosion resistance

• Application Details:
  • Thin film thickness: Usually 0.1–5 µm (microns)
  • Vacuum chamber application
  • Environmentally friendly: No heavy solvents; dry process.
• Special Variants/Notes:
• Limitation: New Parts Only: Pre-installed parts cannot be coated
• Limitations: Size: max length 900mm / typical widths 250mm / contact Weld Dynamix for details
