Hypertherm M12 5-pin 20 m - Abrasion-weld-thermal hybrid · 20 m
Design family Hypertherm
No picture
Technical data
Other
- Keyway Coding
- A-coded
- Color Code
- DC
- HEAD 1 Coupling Nut Gender
- Male
- HEAD 2 Mating Thread Type
- M12
- HEAD 2 Coupling Nut Gender
- Female
- Component Type
- Double-ended cordset
- Wire Gauge
- 22 AWG
- Voltage Rating
- 300
- Shielding
- Yes
- IP Rating
- IP67
- HEAD 1 Mating Thread Type
- M12
- Cable Length in feet
- 65.6
- Cable Length in inches
- 787.4
- Temperature Rating
- -40 °C ... +85 °C
- Body Diameter
- 20 mm
- Overall Body Length
- 57 mm
- Upper AWG
- 20
Other
- Lower AWG
- 28
Connection
- HEAD 1 Pin Gender
- Male
- HEAD 1 Orientation
- Straight
- HEAD 2 Pin Gender
- Female
- Pin Count
- 5
- HEAD 2 Orientation
- Straight
- Matched Connector
- WCA-1204-FXAH
Identification
- Family
- Hypertherm
- Pieces Per Package
Cable
- Cable Jacket Material
- Hybrid
- Cable Armor
- FLEXLINC Springloc
- Cable Length in meters
- 20
Housing
- Shell / Coupling Nut Material
- Metal Alloy
- Body Material
- Nickel Zinc Alloy
- Insulator
- Black Polyamide
- Contacts
- Copper Alloy - Gold Plated
- Seal
- NBR
Certifications
